General Information
Model: 890SD - 532100B0 - B00 - 1A000
Product Name: AC890 Standalone Drive Module
Frame: B
Weight: 6 kg
Protection Class: IP20
Electrical Parameters
Power: 4.0 kW
Input Voltage: 3 - phase 380 - 480 VAC
Rated Output Current: 10.0 A (constant torque rating), 6.00 A (servo mode)
Overload Ratings: Heavy - duty rating (constant torque): 150% for 60 s; Normal - duty rating (variable torque): 110% for 60 s; Servo - mode rating (frames B - D): 200% for 4 s
Power Supply Phase: Three - phase
DC Power Nature: AC
Control Mode: V/F open - loop and closed - loop, sensorless vector control, closed - loop vector control, PMAC servo control
Motor Compatibility
Compatible Motor Types: Brushless servo, frameless servo, induction, spindle, torque, PMAC
Communication and Feedback
Communication Options: Supports a variety of communication protocols such as Modbus, Profibus, Ethernet/IP, etc. (specific options need to be configured according to the actual situation)
Feedback Options: Incremental encoder, EnDat 2.1 (SinCos) encoder, resolver
Environmental Parameters
Operating Temperature: 0 °C to + 45 °C (derate up to 50 °C max)
General Information
Model: 890SD - 532100B0 - B00 - 1A000
Product Name: AC890 Standalone Drive Module
Frame: B
Weight: 6 kg
Protection Class: IP20
Electrical Parameters
Power: 4.0 kW
Input Voltage: 3 - phase 380 - 480 VAC
Rated Output Current: 10.0 A (constant torque rating), 6.00 A (servo mode)
Overload Ratings: Heavy - duty rating (constant torque): 150% for 60 s; Normal - duty rating (variable torque): 110% for 60 s; Servo - mode rating (frames B - D): 200% for 4 s
Power Supply Phase: Three - phase
DC Power Nature: AC
Control Mode: V/F open - loop and closed - loop, sensorless vector control, closed - loop vector control, PMAC servo control
Motor Compatibility
Compatible Motor Types: Brushless servo, frameless servo, induction, spindle, torque, PMAC
Communication and Feedback
Communication Options: Supports a variety of communication protocols such as Modbus, Profibus, Ethernet/IP, etc. (specific options need to be configured according to the actual situation)
Feedback Options: Incremental encoder, EnDat 2.1 (SinCos) encoder, resolver
Environmental Parameters
Operating Temperature: 0 °C to + 45 °C (derate up to 50 °C max)
