Panel Type: It adopts an a - si TFT - LCD structure, which belongs to a transmissive liquid - crystal display. This type of panel has the characteristics of high resolution, fast response speed, and low power consumption, and is suitable for various industrial control and display applications.
Resolution: The resolution is 640×480 (VGA), which can provide relatively clear image display effects and can meet the basic requirements for displaying text, graphics, and simple interface elements in industrial applications.
Display Area and Size: The display area is 116.16 mm (W) × 87.12 mm (H), and the outline size is 127 mm (W) × 100 mm (H) × 8.15 mm (D). The bezel opening is 118.56 mm (W) × 89.52 mm (H). The overall size is compact, which is convenient for installation and use in industrial equipment.
Surface Treatment: The surface is treated with anti - glare and hard coating (3H). The anti - glare treatment can reduce the reflection of light, making the screen easier to read in different lighting environments, while the hard coating can improve the wear - resistance and scratch - resistance of the surface, protecting the panel from being damaged.
Brightness and Contrast: The typical brightness is 180 cd/m², and the contrast ratio is 300:1 (typ.). Such brightness and contrast can ensure that the display content is clear and easy to distinguish, and can present better visual effects in indoor and general - lighting industrial environments.
Viewing Angle: The viewing angle is 70/70/40/60 (typ.) (CR≥10), which means that the horizontal viewing angle is 70 degrees on the left and right, and the vertical viewing angle is 40 degrees upward and 60 degrees downward. Within this range, the display effect is relatively good, and operators can view the screen content clearly from different angles.
Display Mode and Colors: The display mode is TN, normally white, transmissive, and the best viewing angle is at 6 o'clock. It can display 262k colors, which can meet the needs of displaying different colors and gray levels in industrial applications and present rich and vivid visual effects.
Response Time: The response time is 30 ms (typ.) (tr + td), which can quickly update the display content and is suitable for applications that require real - time monitoring and operation, such as in the process of industrial production, where the display needs to quickly reflect the changes in the production status and parameters.
Touch Screen: It is equipped with a 4 - wire resistive touch panel, which has the characteristics of high accuracy and good stability. It can accurately sense the position and pressure of touch operations and provide a convenient human - machine interaction interface for users.
Lamp Type and Frequency: The backlight uses a WLED light source with a service life of 30,000 hours and is equipped with an LED driver. The frequency is 60 Hz, which can provide stable backlight illumination and ensure the stability of the display image.
Signal Interface and Input Voltage: The signal interface is TTL (1 ch, 6 - bit), with 40 pins and a connector. The input voltage is 3.3 V (typ.), which is convenient for connecting to various industrial control devices and systems and realizing data transmission and display control.
Environmental Adaptability: The operating temperature range is - 30 - 85 °C, and the storage temperature range is - 40 - 90 °C. It has strong environmental adaptability and can work stably in harsh industrial environments.
Nee Electron Technology Co.,LTD. is very professional touch panel company. We have Capacitor and resistance touch glass factory can accept OEM .Especial in Automation industrial device. We can do all kind of size which you need exactly.
We can open module in small quantity and fast delievery time and very reasonable price when you can’t find any kind of touch glass.
We export a lot of countries. almost got 100% good feedbacks, Because we have super good team to control our products quality at very strict. Also, we have a professional service team to service you after sold out products.
Just contact us :
Skype: chasesweet2
WeChat: chasesweet
Whatsapp/Mobile: +86 13928128361
Email: chasesweet@163.com
