General Information
Module Type: PLC, FX2N modular extension unit.
Series: Melsec - F series.
Output Type: Relay output.
Occupied I/O Points on PLC: 16.
Integrated Digital Inputs: 16.
Integrated Digital Outputs: 16.
Electrical Characteristics2
Output Signal Voltage: Below DC 30V or AC 240V (Below AC 250V when not compliant with CE, UL, cUL specifications).
Output Current: 2A per point; 8A max for 4 - point common terminal; 8A max for 8 - point common terminal.
Maximum Inductive Load: 80VA.
Open - Circuit Leakage Current: None.
Minimum Load: DC 5V 2mA (reference value).
Mechanical Characteristics
Dimensions: Width 40mm, height 90mm, depth 87mm.
Weight8: 0.3kg.
Installation Method2: DIN - rail mounting on DIN46277 (35mm wide) or direct mounting.
Environmental Characteristics8
ROHS Compliance: Compliant.
REACH Limit Exceeded: No.
Dangerous Goods Regulations: No.
Certification Information
CE Compliant: Yes.
UL/CUL Compliant: Yes.
EAC Compliant: No (Some sources say non - compliant, while others don't mention it).
Shipping Approvals: ABS, BV, DNV GL, KR, LR, NK, RINA. UKCA compliant
General Information
Module Type: PLC, FX2N modular extension unit.
Series: Melsec - F series.
Output Type: Relay output.
Occupied I/O Points on PLC: 16.
Integrated Digital Inputs: 16.
Integrated Digital Outputs: 16.
Electrical Characteristics2
Output Signal Voltage: Below DC 30V or AC 240V (Below AC 250V when not compliant with CE, UL, cUL specifications).
Output Current: 2A per point; 8A max for 4 - point common terminal; 8A max for 8 - point common terminal.
Maximum Inductive Load: 80VA.
Open - Circuit Leakage Current: None.
Minimum Load: DC 5V 2mA (reference value).
Mechanical Characteristics
Dimensions: Width 40mm, height 90mm, depth 87mm.
Weight8: 0.3kg.
Installation Method2: DIN - rail mounting on DIN46277 (35mm wide) or direct mounting.
Environmental Characteristics8
ROHS Compliance: Compliant.
REACH Limit Exceeded: No.
Dangerous Goods Regulations: No.
Certification Information
CE Compliant: Yes.
UL/CUL Compliant: Yes.
EAC Compliant: No (Some sources say non - compliant, while others don't mention it).
Shipping Approvals: ABS, BV, DNV GL, KR, LR, NK, RINA. UKCA compliant
