LM641836
| Availability: | |
|---|---|
| Quantity: | |
| min order: 1 | |
Model: LM641836 (Original OEM Display)
Type: TFT-LCD Module
Technology: a-Si TFT Active Matrix
Backlight: LED (50,000+ Hours Lifetime)
Condition: 100% New & Original
Screen Size: 6.4-inch (4:3 Aspect Ratio)
Resolution: 640 × 480 (VGA)
Active Area: 130.6mm × 97.9mm
Pixel Pitch: 0.204mm × 0.204mm
Brightness: 350 cd/m² (Typical)
Contrast Ratio: 500:1 (Min.)
Viewing Angle: 140° (H) / 130° (V)
Color Depth: 262K (6-bit + FRC)
Interface: LVDS (Single-Channel, 18/24-bit)
Operating Voltage: 3.3V (Logic) / 5V (Backlight)
Power Consumption: ≤3.5W (Typical)
Connector: 20-Pin FPC (0.5mm Pitch)
Module Dimensions: 165mm × 120mm × 10.5mm
Weight: ~280g
Mounting: 4x M2.5 Screw Holes
Bezel Material: Metal Frame (EMI Shielded)
Operating Temperature: -20°C to +70°C
Storage Temperature: -30°C to +80°C
Humidity Resistance: 85% RH (Non-Condensing)
MTBF: 50,000 Hours (at 25°C)
Common Applications:
Industrial Control Panels
Medical Monitoring Devices
Test & Measurement Equipment
Automotive Displays
Nee Electron Technology Co.,LTD. is very professional touch panel company. We have Capacitor and resistance touch glass factory can accept OEM .Especial in Automation industrial device. We can do all kind of size which you need exactly.
We can open module in small quantity and fast delievery time and very reasonable price when you can’t find any kind of touch glass.
We export a lot of countries. almost got 100% good feedbacks, Because we have super good team to control our products quality at very strict. Also, we have a professional service team to service you after sold out products.
Just contact us :
Skype: chasesweet2
WeChat: chasesweet
Whatsapp/Mobile: +86 13928128361
Email: chasesweet@163.com
Model: LM641836 (Original OEM Display)
Type: TFT-LCD Module
Technology: a-Si TFT Active Matrix
Backlight: LED (50,000+ Hours Lifetime)
Condition: 100% New & Original
Screen Size: 6.4-inch (4:3 Aspect Ratio)
Resolution: 640 × 480 (VGA)
Active Area: 130.6mm × 97.9mm
Pixel Pitch: 0.204mm × 0.204mm
Brightness: 350 cd/m² (Typical)
Contrast Ratio: 500:1 (Min.)
Viewing Angle: 140° (H) / 130° (V)
Color Depth: 262K (6-bit + FRC)
Interface: LVDS (Single-Channel, 18/24-bit)
Operating Voltage: 3.3V (Logic) / 5V (Backlight)
Power Consumption: ≤3.5W (Typical)
Connector: 20-Pin FPC (0.5mm Pitch)
Module Dimensions: 165mm × 120mm × 10.5mm
Weight: ~280g
Mounting: 4x M2.5 Screw Holes
Bezel Material: Metal Frame (EMI Shielded)
Operating Temperature: -20°C to +70°C
Storage Temperature: -30°C to +80°C
Humidity Resistance: 85% RH (Non-Condensing)
MTBF: 50,000 Hours (at 25°C)
Common Applications:
Industrial Control Panels
Medical Monitoring Devices
Test & Measurement Equipment
Automotive Displays
Nee Electron Technology Co.,LTD. is very professional touch panel company. We have Capacitor and resistance touch glass factory can accept OEM .Especial in Automation industrial device. We can do all kind of size which you need exactly.
We can open module in small quantity and fast delievery time and very reasonable price when you can’t find any kind of touch glass.
We export a lot of countries. almost got 100% good feedbacks, Because we have super good team to control our products quality at very strict. Also, we have a professional service team to service you after sold out products.
Just contact us :
Skype: chasesweet2
WeChat: chasesweet
Whatsapp/Mobile: +86 13928128361
Email: chasesweet@163.com
