Home » Products » LCD Panel & Touch Screen » LMCGAH032J75CGKS LCD Panel

PRODUCT DETAIL

LMCGAH032J75CGKS LCD Panel LMCGAH032J75CGKS LCD Panel

loading

LMCGAH032J75CGKS LCD Panel

5 0 Reviews
LMCGAH032J75CGKS LCD Panel
Price: $ 157
  • LMCGAH032J75CGKS

Availability:
Quantity:

LMCGAH032J75CGKS LCD Panel Specifications

Product Overview

  • Model: LMCGAH032J75CGKS (Original OEM Panel)

  • Type: TFT-LCD Module

  • Technology: a-Si TFT Active Matrix

  • Backlight: LED (50,000+ Hours Lifetime)

  • Condition: New & Original


Technical Specifications

1. Display Characteristics

  • Screen Size: 3.2-inch (Custom Aspect Ratio)

  • Resolution: 320 × 240 (QVGA)

  • Active Area: 65.0mm × 48.7mm

  • Pixel Pitch: 0.203mm × 0.203mm

  • Brightness: 250 cd/m² (Typical)

  • Contrast Ratio: 500:1 (Min.)

  • Viewing Angle: 70°/70°/50°/70° (L/R/U/D)

  • Color Depth: 262K (6-bit + FRC)

2. Electrical Specifications

  • Interface: RGB (24-bit) or MCU (8/16-bit)

  • Operating Voltage: 3.3V (Logic) / 5V (Backlight)

  • Power Consumption: ≤1.5W (Typical, LED Backlight)

  • Connector: 40-Pin FPC (0.5mm Pitch, OEM Standard)

3. Mechanical Specifications

  • Module Dimensions: 75mm × 60mm × 5.5mm

  • Weight: ~50g

  • Mounting: 4x M1.6 Screw Holes (OEM-Compatible)

  • Bezel Material: Metal Frame (EMI Shielded)

4. Environmental & Reliability

  • Operating Temperature: -20°C to +70°C

  • Storage Temperature: -30°C to +80°C

  • Humidity Resistance: 85% RH (Non-Condensing)

  • MTBF: 50,000 Hours (at 25°C)

5. Compatibility

  • Used In:

    • Industrial HMIs

    • Portable Medical Devices

    • Automotive Displays

    • Consumer Electronics

Nee Electron Technology Co.,LTD. is very professional touch panel company. We have Capacitor and resistance touch glass factory can accept OEM .Especial in Automation industrial device. We can do all kind of size which you need exactly.

We can open module in small quantity and fast delievery time and very reasonable price when you can’t find any kind of touch glass.

We export a lot of countries. almost got 100% good feedbacks, Because we have super good team to control our products quality at very strict. Also, we have a professional service team to service you after sold out products.

Just contact us :

Skype: chasesweet2

WeChat: chasesweet

Whatsapp/Mobile: +86 13928128361

Email: chasesweet@163.com

LMCGAH032J75CGKS
