MSG160128CFT1 LCD Panel

General Characteristics

• The MSG160128CFT1 is a character and graphic LCD panel. It is designed to display text and simple graphics, making it suitable for a variety of applications where detailed visual information is not the main focus.

Technical Specifications

• Resolution: It has a resolution of 160×128 pixels. This relatively low - resolution is sufficient for displaying basic text and simple graphical elements, such as icons and simple line drawings. It is commonly used in applications where space is limited and high - definition displays are not required.

• Display Type: It is likely a negative - mode display, which means that the characters or graphics are displayed as dark on a light background. This type of display offers good contrast and visibility in normal lighting conditions.

• Color: Usually, it is a monochrome display, typically in black and white or with a single - color backlight, such as blue or green. The simplicity of the color scheme helps in reducing power consumption and cost.

• Viewing Angle: The viewing angle of the MSG160128CFT1 is moderate. It can be clearly viewed from a relatively wide range of angles horizontally, but the vertical viewing angle may be more limited. However, for its typical applications, the viewing angle is sufficient to ensure that the display is visible to the user.

Electrical and Physical Attributes

• Power Supply: It operates at a specific DC voltage, often around 3.3V or 5V. The power consumption is relatively low, which is beneficial for battery - powered devices or applications where energy efficiency is important.

• Size and Mounting: The physical size of the panel is designed to be compact, suitable for integration into small devices. It usually comes with standard mounting holes or a mounting structure that allows it to be easily installed in various enclosures or device housings.

Applications

• Industrial Controls: In industrial control systems, it can be used to display simple status information, such as the on - off status of equipment, process parameters in a basic format, and error messages. Its reliability and simplicity make it a suitable choice for harsh industrial environments.

• Consumer Electronics: It is often found in consumer electronics products like simple digital clocks, calculators, and basic electronic toys. The monochrome display and low - resolution are sufficient for these applications, and the low power consumption helps in extending the battery life of these devices.

• Medical Devices: Some basic medical devices, such as simple patient monitors or blood pressure monitors, may use the MSG160128CFT1 to display essential patient data in a clear and easy - to - read format.

Nee Electron Technology Co.,LTD. is very professional touch panel company. We have Capacitor and resistance touch glass factory can accept OEM .Especial in Automation industrial device. We can do all kind of size which you need exactly.

We can open module in small quantity and fast delievery time and very reasonable price when you can’t find any kind of touch glass.

We export a lot of countries. almost got 100% good feedbacks, Because we have super good team to control our products quality at very strict. Also, we have a professional service team to service you after sold out products.

Just contact us :

Skype: chasesweet2

WeChat: chasesweet

Whatsapp/Mobile: +86 13928128361

Email: chasesweet@163.com
