MSR124RT 440R-G23110 New and original relay

Input: 1NC or 2NC or light curtain

Single wire safe input: N/A

Logic configuration: None

Immediate safety outputs: 5NO

Immediate auxiliary outputs: 1NC

Delayed safety outputs: N/A

Single wire safe output: N/A

Power supply: 24V AC/DC

Removable terminals: Fixed

Reset: Configured automatic/manual or manual monitored reset

Contact rating: DC - 13 10A/24V DC, 0.1Hz

Enclosure: 100mm

Standard: CE/CULus/C - tick

Additional parameters:

Input power entry: 24V AC/DC, 115/230V AC, 50/60Hz

Power consumption: <4VA

Input simultaneity: 0.5 seconds

Input resistance, max: 500Ω

Response time: 50ms

Thermal current ilth: 4A (non - switching)

Rated impulse withstand voltage ilth: 2500V

Switching current @ voltage, min: 10mA @ 10V

Fuses, output (external) : 5A quick - acting (external)

Electrical life (operations) : 220V AC/4A/880VA cosφ = 0.35…0.1M; 220V AC/1.7A/375VA cosφ = 0.6…0.5M; 30V DC/2A/60W = 1M; 10V DC/0.01A/0.1W = 2M

Mechanical life: 2,000,000 operations

Utilization category: A 600/AC - 15 (Ue) 600V 500V 240V 120V, (Le) 1.2A 1.4A 3A 6A; N 600/DC - 13 (Ue) 600V 500V 250V 120V, (Le) 0.4A 0.55A 1.1A 2.2A

Environmental: Enclosure type rating/Terminal protection IP40 (NEMA 1), DIN 0470/IP20, DIN 0470; Operating temperature -10…+55°C (14…131°F); Vibration 0.75mm (0.30in.) peak, 10…55Hz; Shock 30g, 11ms half - sine

Physical characteristics: Mounting 35mm DIN rail
