New 127x100 mm 127*100mm 4wire touch screen
Availability: | |
---|---|
Quantity: | |
min order: 1 | |
Type: 4-Wire Resistive Touch Screen
Technology: Analog Resistive (Polyester Film + ITO Glass)
Active Area: 127mm × 100mm
Total Thickness: 1.3mm (standard)
1. Physical Characteristics
Outline Dimensions: 135mm × 108mm (frame size)
Surface Material: Hard-coated PET film (anti-scratch)
Bottom Layer: ITO-coated glass
Connector Type: FPC (ZIF connector, 10-pin standard)
2. Touch Performance
Touch Points: Single-touch (4-wire resistive)
Actuation Force: 50–100g
Response Time: <10ms
Linearity Error: <1.5%
Durability: >5 million touches
3. Electrical Characteristics
Operating Voltage: 5V DC
Interface: Analog resistive (X/Y output)
Insulation Resistance: >100MΩ
Power Consumption: <10mA
4. Environmental & Durability
Operating Temperature: -20°C to +70°C
Storage Temperature: -30°C to +85°C
Humidity Resistance: 90% RH (non-condensing)
Surface Hardness: 3H (pencil hardness)
5. Optical Properties
Light Transmittance: ≥82%
Haze: <1.5%
Surface Finish: Glossy or matte (optional)
Type: 4-Wire Resistive Touch Screen
Technology: Analog Resistive (Polyester Film + ITO Glass)
Active Area: 127mm × 100mm
Total Thickness: 1.3mm (standard)
1. Physical Characteristics
Outline Dimensions: 135mm × 108mm (frame size)
Surface Material: Hard-coated PET film (anti-scratch)
Bottom Layer: ITO-coated glass
Connector Type: FPC (ZIF connector, 10-pin standard)
2. Touch Performance
Touch Points: Single-touch (4-wire resistive)
Actuation Force: 50–100g
Response Time: <10ms
Linearity Error: <1.5%
Durability: >5 million touches
3. Electrical Characteristics
Operating Voltage: 5V DC
Interface: Analog resistive (X/Y output)
Insulation Resistance: >100MΩ
Power Consumption: <10mA
4. Environmental & Durability
Operating Temperature: -20°C to +70°C
Storage Temperature: -30°C to +85°C
Humidity Resistance: 90% RH (non-condensing)
Surface Hardness: 3H (pencil hardness)
5. Optical Properties
Light Transmittance: ≥82%
Haze: <1.5%
Surface Finish: Glossy or matte (optional)
