New and original HMI TS1100i-119 TS1100i New and original HMI TS1100i-119 TS1100i
New and original HMI TS1100i-119 TS1100i New and original HMI TS1100i-119 TS1100i

loading

New and original HMI TS1100i-119 TS1100i

5 0 Reviews
New and original HMI TS1100i-119 TS1100i
Price: $ 598
  • HMI TS1100i-119 TS1100i

Availability:
Quantity:
min order: 1
View wholesale prices View wholesale prices
  • Quantity Price
  • 5 $-5
sign in to view wholesale price

Product Overview

  • Model: TS1100i-119 / TS1100i (Genuine OEM Unit)

  • Type: Industrial HMI Touch Panel

  • Display Technology: TFT-LCD with Resistive Touch

  • Condition: 100% New & Original

  • Manufacturer: Schneider Electric / Magelis


Technical Specifications

1. Display Characteristics

  • Screen Size: 10.4-inch (4:3 Aspect Ratio)

  • Resolution: 640 × 480 (VGA)

  • Active Area: 211mm × 158mm

  • Brightness: 300 cd/m²

  • Contrast Ratio: 500:1

  • Viewing Angle: 140° (H) / 130° (V)

  • Backlight: LED (50,000 Hours Lifetime)

2. Touch Panel

  • Technology: 5-Wire Resistive Touch

  • Touch Points: Single Touch

  • Durability: 1 Million Touches

  • Surface Hardness: 3H Pencil Hardness

3. Processing Unit

  • CPU: 32-bit RISC Processor

  • Memory: 128MB Flash / 64MB RAM

  • OS: VxWorks RTOS

4. Communication Interfaces

  • Serial Ports:

    • 1× RS-232 (Configurable as RS-485)

    • 1× RS-485 (Isolated)

  • Ethernet: 10/100Mbps RJ45

  • USB: 1× USB 2.0 Host

5. Electrical Specifications

  • Power Input: 24V DC (19.2–28.8V)

  • Power Consumption: ≤15W

  • Isolation: 1500V AC (RS-485 Port)

6. Environmental Specifications

  • Operating Temperature: 0°C to +50°C

  • Storage Temperature: -20°C to +70°C

  • Humidity: 10–90% RH (Non-Condensing)

  • Protection: IP65 Front Panel

7. Software Compatibility

  • Development Software: Vijeo Designer

  • Supported Protocols:

    • Modbus RTU/ASCII/TCP

    • Schneider Electric Uni-Telway

    • Ethernet/IP

    • CANopen

8. Mechanical Specifications

  • Dimensions: 290mm × 220mm × 55mm

  • Panel Cutout: 276mm × 206mm

  • Weight: 2.5kg

  • Mounting: Panel Mount (Front Mount)


Nee Electron Technology Co.,LTD. is very professional touch panel company. We have Capacitor and resistance touch glass factory can accept OEM .Especial in Automation industrial device. We can do all kind of size which you need exactly.

We can open module in small quantity and fast delievery time and very reasonable price when you can’t find any kind of touch glass.

We export a lot of countries. almost got 100% good feedbacks, Because we have super good team to control our products quality at very strict. Also, we have a professional service team to service you after sold out products.

Just contact us :

Skype: chasesweet2

WeChat: chasesweet

Whatsapp/Mobile: +86 13928128361

Email: chasesweet@163.com

HMI TS1100i-119 TS11 00iHMI TS1100i-119 TS1100i
