New and original HMI UG530H-VS1

5 0 Reviews
New and original HMI UG530H-VS1
Price: $ 1380
  • HMI UG530H-VS1

Availability:
Quantity:
min order: 1
View wholesale prices View wholesale prices
  • Quantity Price
  • 5 $-5
sign in to view wholesale price


Product Overview

  • Model: UG530H-VS1 (Genuine OEM Unit)

  • Type: Industrial HMI Touch Panel

  • Display Technology: TFT-LCD with Projected Capacitive Touch

  • Condition: 100% New & Original

  • Manufacturer: Weintek/Maple Systems


Technical Specifications

1. Display Characteristics

  • Screen Size: 5.7-inch

  • Resolution: 320 × 240 (QVGA)

  • Active Area: 115mm × 86mm

  • Brightness: 250 cd/m²

  • Contrast Ratio: 500:1

  • Viewing Angle: 70°/70°/50°/70° (L/R/U/D)

  • Backlight: LED (50,000 Hours Lifetime)

2. Touch Panel

  • Technology: 4-Wire Resistive Touch

  • Touch Points: Single Touch

  • Durability: 1 Million Touches

  • Surface Hardness: 3H Pencil Hardness

3. Processing Unit

  • CPU: 32-bit RISC Processor

  • Memory: 128MB Flash / 64MB RAM

  • OS: Embedded Linux

4. Communication Interfaces

  • Serial Ports:

    • 1× RS-232 (Configurable as RS-485)

    • 1× RS-485 (Isolated)

  • Ethernet: 10/100Mbps RJ45

  • USB: 1× USB 2.0 Host

5. Electrical Specifications

  • Power Input: 24V DC (10.8~28.8V)

  • Power Consumption: ≤10W

  • Isolation: 1500V AC (RS-485 Port)

6. Environmental Specifications

  • Operating Temperature: 0°C to +50°C

  • Storage Temperature: -20°C to +70°C

  • Humidity: 10~90% RH (Non-Condensing)

  • Protection: IP65 Front Panel

7. Software Compatibility

  • Development Software: EasyBuilder Pro

  • Supported Protocols:

    • Modbus RTU/ASCII/TCP

    • Allen-Bradley DF1

    • Siemens PPI

    • Omron Host Link

8. Mechanical Specifications

  • Dimensions: 160mm × 117mm × 40mm

  • Panel Cutout: 152mm × 109mm

  • Weight: 0.6kg

  • Mounting: Panel Mount (Front Mount)

Nee Electron Technology Co.,LTD. is very professional touch panel company. We have Capacitor and resistance touch glass factory can accept OEM .Especial in Automation industrial device. We can do all kind of size which you need exactly.

We can open module in small quantity and fast delievery time and very reasonable price when you can’t find any kind of touch glass.

We export a lot of countries. almost got 100% good feedbacks, Because we have super good team to control our products quality at very strict. Also, we have a professional service team to service you after sold out products.

Just contact us :

Skype: chasesweet2

WeChat: chasesweet

Whatsapp/Mobile: +86 13928128361

Email: chasesweet@163.com

New and origi nal HMI UG530H-VS1HMI UG530H-VS1
