New touch screen for GT32 AIG32MQ03D

Product Name: Replacement Touch Screen for GT32 (AIG32MQ03D)

Type: Projected Capacitive Touch Panel (PCAP)

Compatible Model: Designed for GT32 / AIG32MQ03D display module

Material & Construction:

• Cover Lens: Tempered glass (chemically strengthened)

• Sensor Layer: ITO (Indium Tin Oxide) film/glass

• Bonding Technology: Optical bonding (OCA) or air gap (depending on configuration)

Dimensions & Specifications:

• Screen Size: 3.2 inches (diagonal)

• Active Area: 65.0mm × 48.0mm (exact match for AIG32MQ03D)

• Total Thickness: 1.2mm ±0.1mm (cover glass only)

• Outline Dimensions: 70.0mm × 53.0mm (mounting holes aligned with GT32 display)

Touch Performance:

• Touch Points: Multi-touch (2~5 points, depends on controller)

• Sensitivity: ≤5ms response time

• Operating Voltage: 3.3V (standard)

• Communication Interface: I²C or USB (configurable)

Durability & Environmental Ratings:

• Surface Hardness: ≥7H (scratch-resistant)

• Coating Options: Anti-glare (AG), Anti-fingerprint (AF)

• Operating Temperature: -20°C to +70°C

• Storage Temperature: -30°C to +80°C

• Humidity Range: Up to 90% RH (non-condensing)

Optical Properties:

• Transmittance: ≥90% (550nm wavelength)

• Haze: ≤0.5% (clear visibility)

Compatibility & Integration:

• Controller Compatibility: Supports FT5x06, GT911, and other common ICs

• Driver Support: Plug-and-play for Android, Linux, Windows

• Sealing Options: IP65-rated (optional for industrial use)

Certifications & Standards:

• RoHS & REACH compliant

• CE/FCC certification support (upon request)

Applications:

• Replacement for GT32/AIG32MQ03D in industrial HMI

• Medical equipment touchscreen upgrades

• Automotive dashboards and control panels
