PC130-7 touch LCD Panel

General Information

• Panel Type: TFT - LCD with touch screen

• Size: 13.0 inches

• Aspect Ratio: 16:9

Resolution

• Resolution: 1280×800

Optical Parameters

• Brightness: 300 nits (typical)

• Contrast Ratio: 1000:1 (typical)

• Viewing Angle: 80/80/80/80 (left/right/up/down, typical), in degrees

• Color Gamut: 72% NTSC (typical)

Touch Screen Parameters

• Touch Technology: Resistive or capacitive (depending on the specific model)

• Touch Response Time: Less than 10 ms (typical)

• Touch Life: More than 1 million times (typical)

Electrical Parameters

• Power Supply Voltage: 12V DC (typical)

• Power Consumption: 20W (typical)

Physical Dimensions

• Active Area: 285.76×180.16 mm

• Overall Size: Approximately 315×210×10 mm (including the bezel)

• Weight: Around 0.8 kg

Temperature Range

• Operating Temperature: -20°C to 70°C

• Storage Temperature: -30°C to 80°C
