TCG057VGLPBANN-G New and original LCD Panel

1. Display Specifications

• Resolution: 640(RGB)×480 (VGA), with an RGB vertical - stripe pixel layout, which can display relatively rich graphic and text information.

• Color: It can display 262K colors (6 - bit), with a color gamut of 52% (CIE1931), presenting relatively vivid colors.

• Brightness: The typical brightness is 450 cd/m², which is suitable for use in various environments and can ensure clear visibility of the screen.

• Contrast Ratio: The typical contrast ratio is 500:1 (transmissive), which can clearly distinguish light and dark areas, making the image more vivid and detailed.

• Viewing Angle: The viewing angle is 80/80/80/80 (Typ.)(CR≥10), meaning that the screen can be clearly seen from multiple directions, with good viewing effect.

• Response Time: The response time is 10/25 (Typ.)(Tr/Td) ms, which can meet the basic needs of dynamic image display.

2. Physical Characteristics

• Display Size: The display size is 115.2×86.4 mm (H×V), and the visual size is 117.2×88.4 mm (H×V).

• Overall Dimensions: The overall dimensions are 127.2×100.4×6 mm (H×V×D), and the net weight is about 110 g, which is relatively compact and lightweight, suitable for integration into various industrial equipment.

3. Electrical Characteristics

• Signal System: It adopts LVDS (1 ch, 6 - bit) signal system, with terminals and 30 pins, which can realize high - speed and stable data transmission.

• Supply Voltage: The supply voltage is 3.3V (Typ.), with low power consumption and high stability.

4. Environmental Specifications

• Operating Temperature: The operating temperature range is - 20℃ - 70℃, and the storage temperature range is - 30℃ - 80℃, which can adapt to a variety of harsh environmental conditions.

Nee Electron Technology Co.,LTD. is very professional touch panel company. We have Capacitor and resistance touch glass factory can accept OEM .Especial in Automation industrial device. We can do all kind of size which you need exactly.

We can open module in small quantity and fast delievery time and very reasonable price when you can’t find any kind of touch glass.

We export a lot of countries. almost got 100% good feedbacks, Because we have super good team to control our products quality at very strict. Also, we have a professional service team to service you after sold out products.
