TP-3342S1 new Touch glass
TP-3342S1 new Touch glass TP-3342S1 new Touch glass

loading

TP-3342S1 new Touch glass

5 0 Reviews
TP-3342S1 new Touch glass
Price: $ 77
  • TP-3342S1

Availability:
Quantity:
min order: 1
View wholesale prices View wholesale prices
  • Quantity Price
  • 5 $-5
sign in to view wholesale price

Product Name: TP-3342S1 New Touch Glass

Product Type: Capacitive Touch Panel (CTP)

Material:

  • Cover Lens: Chemically strengthened glass (Aluminosilicate)

  • Sensor Layer: ITO (Indium Tin Oxide) coating

  • Optical Bonding: OCAdhesive (optional)

Dimensions:

  • Size: 3.3 inches (diagonal)

  • Thickness: 1.1mm ±0.1mm

  • Active Area: 70.0mm × 46.0mm

  • Outline Dimensions: 75.0mm × 51.0mm

Touch Performance:

  • Touch Points: Single-touch/Multi-touch (up to 5 points, depending on controller)

  • Response Time: ≤8ms

  • Operating Voltage: 2.8V ~ 3.3V

  • Interface: I²C, SPI (customizable)

Durability & Environmental Resistance:

  • Hardness: ≥7H (Mohs scale)

  • Surface Treatment: Anti-glare, Anti-fingerprint (AF coating optional)

  • Operating Temperature: -20°C ~ +70°C

  • Storage Temperature: -30°C ~ +80°C

  • Humidity Resistance: 90% RH (non-condensing)

Optical Properties:

  • Transmittance: ≥88% (550nm wavelength)

  • Haze: ≤1%

Compatibility:

  • Controller IC: Compatible with major drivers (FT5x06, GT9xx, etc.)

  • OS Support: Windows, Android, Linux

Certifications:

  • RoHS compliant

  • REACH compliant

Applications:

  • Industrial control panels

  • Medical devices

  • Automotive displays

  • Smart home systems


TP-3342S1
