VT3-V10 new and original touch glass

General Information

• Product Name: VT3 - V10 Touch Screen

• Purpose: Display and touch operation, suitable for all industries.

Electrical Characteristics

• Rated Voltage: 100 - 240VAC ± 10% (50/60Hz)

• Power Consumption: Less than 65VA

Performance Specifications

• Display Panel:

• Display Element: TFT - color LCD

• Display Colors: 32,768 colors

• Dot Resolution: 640×480

• Active Display Area: 211.2×158.4mm

• Service Life: Approximately 50,000 hours

• Backlight System: White LED (non - replaceable), with a lifespan of about 50,000 hours

• Touch Screen:

• Switch Type: Matrix resistive film

• Number of Switches: 40×30 per screen

• Actuation Force: Less than 0.98N

• Lifespan: More than 1 million times

Environmental Specifications

• Operating Environment: Dust - free and non - corrosive gas - free environment preferred

• Operating Temperature: 0 - 50°C

• Operating Humidity: 35 - 85% RH (no condensation)

• Storage Temperature: - 10 - 60°C (no freezing)

• Storage Humidity: 35 - 85% RH (no condensation)

Physical Characteristics

• Weight: Approximately 2300g

• Structure: Panel - mounted type, with a dust - proof and splash - proof structure equivalent to IP65f on the front - operating part only.
